CANLTW - CAN Connection Cable for G4X/G4+ WireIn ECU’s (6 Pin CAN)
Link
CANLTW - CAN Connection Cable for G4X/G4+ WireIn ECU’s (6 Pin CAN)
Used to add CAN communication to the WireIn ECUwhich has CAN access via the 6-pin round CAN connector on the front of the ECU.
Compatible ECUs:
G5 Voodoo Pro (CAN1)
G4X/G4+ Xtreme (CAN1)
G4X/G4+ Fury (CAN1)
G4+ Force (CAN1)
G4+ Thunder (CAN1)
Specifications:
DTM4 Male to LTW 6Pin.
12V and ground via loose leads.
Reviews
Help others choose right. Be the first to write a review!
Write a reviewCANLTW - CAN Connection Cable for G4X/G4+ WireIn ECU’s (6 Pin CAN)
Used to add CAN communication to the WireIn ECU
which has CAN access via the 6-pin round CAN connector on the front of the ECU.
Compatible ECUs:
- G5 Voodoo Pro (CAN1)
- G4X/G4+ Xtreme (CAN1)
- G4X/G4+ Fury (CAN1)
- G4+ Force (CAN1)
- G4+ Thunder (CAN1)
Specifications:
- DTM4 Male to LTW 6Pin.
- 12V and ground via loose leads.
- CAN cable length: 300 mm (Loose leads length: 500 mm)
DTM4 Pin Out:
- Pin 4: CAN H
- Pin 3: CAN L
- Pin 2: Ground
- Pin 1: 12V
----------------
